FireBoard Drive Blower 20 CFM — Frequently Asked Questions
What is the FireBoard Drive Blower?
The FireBoard Drive Blower (e.g. G3 model) is a variable‐speed fan designed for use with FireBoard’s Drive system. It provides up to 20 CFM of airflow to help regulate and maintain stable pit temperatures by forcing air into the smoker or grill.
Which models and systems is the blower compatible with?
The blower is designed to work with FireBoard Drive / FireBoard 2 Drive / Pro units. It can also be used in legacy setups with a Drive Fan Control Cable.
What are its specifications (airflow, power, dimensions, adapters)?
• Maximum flow: 20 CFM
• Blower opening: 1.2″ × 1.6″ (30 × 40 mm)
• Flange outer dimensions: 1.95″ × 2.45″ (49 × 62 mm)
• Mounting hole spacing: 1.32″ × 2.05″ (34 × 52 mm)
• Power: 12 VDC, 0.68 A, ~8 W
• Cable length: ~4.5 ft (1.4 m) with a 2.5 mm barrel plug connector
• Adapter plates: includes Small/Medium and Large/XL adapter plates to match different smoker vent sizes
• Additional features: G3 model includes a built-in rotating damper for fine airflow control and breakaway adapter plates for more flexible mounting.
Does the blower include a fan control cable?
No — the blower does **not** include the Drive Fan Control Cable. For use with FireBoard 2 or FBX11 (if they don’t have built-in Drive support), that cable is required. However, FireBoard 2 Drive / Pro models can power the blower directly without needing the cable.
How do I mount and install the blower?
1. Pick the correct adapter plate (small/medium or large/XL) to match your smoker’s vent opening.
2. Loosen the thumb screws / rails on the blower, slide the selected adapter plate into position, and secure it.
3. Use the rotating damper (on G3) to fine-tune airflow without removing the blower.
4. Connect power via 12 V supply or directly from a compatible FireBoard Drive / Pro unit.
5. Seal any gaps to avoid air leaks and test airflow before cooking.
How does this blower affect cooking performance?
When used properly, it improves stability in smokers by providing consistent airflow, enabling the controller to respond dynamically to maintain a set temperature. However, because it delivers 20 CFM, overuse or improper adjustment (too much airflow) might overdrive the fire and cause spikes. Some users report needing to partially close the damper to tame airflow depending on the cooker size.
What is the warranty or return policy?
Warranty and return policies depend on the retailer and FireBoard’s terms. Typically, new units are warranted against defects and returns are accepted if the item is unused and within the return window. Check with the seller you purchase from for specifics.
